LPPL000-16A-4910-4005-84S-FO32-EN Electric Pneumatic Integrated Slip Rings

share
copy Link
Facebook
Twitter
LinkedIn
Consult immediately
DetailInstallationReview(0)

Description:

A pneumatic rotary union is a mechanism used to transfer fluid (under pressure or vacuum) from a stationary inlet to a rotating outlet, preserving and isolating the fluid connection.

Pneumatic rotary union are engineered to endure a wide range of temperatures and pressures for a variety of conditions and environments. In addition, rotary unions may integrate multiple passages and handle different types of fluid simultaneously.


Electrical&ElectronicsMechanical
Circuitstotal173CKTWorking Speed
0~90 rpm
Detail49*10A+40*5A+84*SignalInner Diameter
/
Rating Voltage
220V(P)/12VDC(S)Contact Material
Precious Metal
Dielectric Stength

500VAC@50Hz (P)
100VAC@50Hz(S)

Housing Material
Aluminum Alloy
Insulation Resistance

≥500MΩ@500VDC(P)

≥100MΩ@100VDC(S)

Lead Wire Length

Stator:1000mm

Rotor:1000mm

Environment
Remarks
Working Temperature
-20°C~+60°CApplication
/
Working Humidity
≤60%RHOther
/
IPIP40(Horizontal installation)Note:"P"stands for power ,"S"stands for signal




LPPL000-16A-4910-4005-84S-FO32-EN-Outline Drawing
