High Frequency Slip Rings

share
copy Link
Facebook
X
LinkedIn
Number of Circuits 1/2/3/4(optiongal)
Insertion loss max 0.25dB(Minimum)
Frequency range 1CH:≤50GHz 2CH:≤18GHz
VSWR,max 1.2(Minimum)
Consult immediately
DetailInstallationReview(0)

High Frequency Rotary Joint is applied in constant rotating devices. It transmits high frequency signal and high speed signal from stationary part to rotary part. This rotary joint is able to transfer analog signals and high-speed digital signals with frequencies up to 500MHz-50GHz. It is compact in structure, stable in performance with good shielding effect, and low interference. Besides, high frequency slip ring can be easily installed in other applications. This series consists of high frequency slip ring and high frequency electric hybrid slip ring


electrical rotary union Features:

◎ Up to 4 circuits (model with more circuits is customizable)

◎ Frequency up to 50GHz

◎ Compact structure with low interference

◎ Transmit multifarious signals simultaneously

◎ Ultra low insertion loss and transmission fluctuation

◎ Long service life and maintenance-free


Applications:

◎ Radar antenna, military system devices

◎ HD network video surveillance system

◎ Satellite communication system

◎ Medical treatment instrument

◎ Air traffic control and missile defense system



High Frequency Slip Rings
Single-ChannelModelChannelInterfaceFrequency
range

Peak

power,max

Average

power, max

VSWR，maxInsertion loss，max

Isolation

,min

Details
LPCC-01A1

Optional

DC-3GHz1000W20W@3GHz1.5@0-3GHz

1.2dB@3GHz

（250mm/250mm）

/详情.png
LPCC-02A1

Optional

DC-3GHz1000W20W@3GHz1.6@0-3GHz1.2dB@3GHz

（250mm/250mm）

/详情.png
LPCC-01B1

Optional

DC-6GHz800W10W@6GHz1.5@6GHz

1.8dB@0-6G

（250mm/250mm）

/详情.png
LPHF-01A1SMA-f(50Ω)DC-18GHz1500W

200W@1GHz

30W@18GHz

1.20@0-6GHz

1.25@6-12GHz

1.35@12-18GHz

0.25dB@0-6GHz

0.3dB@6-12GHz

0.5dB@12-18GHz

/详情.png
LPHF-01C1SMA-f(50Ω)DC-18GHz3000W

200W@1GHz

30W@18GHz

1.2@0-6GHz

1.3@6-12GHz

1.4@12-18GHz

0.25dB@0-6GHz

0.3dB@6-12GHz

0.4dB@12-18GHz

/详情.png
LPHF-01E13.5mm-f(50Ω)DC-26.5GHz3000W

200W@1GHz

50W@18GHz

30W@26.5GHz

1.30@0-12GHz

1.35@12-18GHz

1.7@18-26.5GHz

0.3dB@0-12GHz

0.35dB@12-18GHz

0.7dB@18-26.5GHz

/详情.png
LPHF-01F12.92mm-f(50Ω)DC-40GHz500W

50W@2GHz

2W@18GHz

1W@40GHz

1.4@0-18GHz

1.7@18-26.5GHz

2.0@26.5-40GHz

0.5dB@0-18GHz

1.0dB@18-26.5GHz

1.2dB@26.5-40GHz

/详情.png
LPHF-01G12.4mm-f(50Ω)DC-50GHz1000W

50W@1GHz

15W@10GHz

3W@50GHz

1.3@0-10GHz

1.4@10-26.5GHz

1.7@26.5-50GHz

0.3dB@0-10GHz

0.5dB@10-26.5GHz

0.9dB@26.5-50GHz

/详情.png


LPHF-01K


1L36-F(50Ω)DC-30MHz20KW15kw1.20.5dB/详情.png
LPHF-01H1N-F-f(50Ω)DC-18GHz1000W

200W@1GHz

100W@8GHz

70W@18GHz

1.2@0-10GHz

1.3@10-18GHz

0.2dB@0-10GHz

0.3dB@10-18GHz

/详情.png
LPHF-01M1SMA-f(50Ω)DC-18GHz3000W200W@1GHz

1.35@0-10GHz

1.5@10-18GHz

0.3dB@0-10GHz

0.4dB@10-18GHz

/详情.png
2SMA-f(50Ω)DC-4.5GHz1000W10W1.50.3dB
LPHF-02B2SMA-f(50Ω)DC-18GHz1000W200W@1GHz

1.3@0-8GHz

1.5@4-18GHz

0.4dB@0-4GHz

0.9dB@4-18GHz

SMA-f(50Ω)DC-4GHz1000W200W@1GHz1.50.5dB
LPHF-02C2SMA-f(50Ω)DC-18GHz1000W

100W@2GHz

60W@8GHz

10W@18GHz

1.35@0-8GHz

1.5@8-18GHz

0.4dB@0-8GHz

0.9dB@8-18GHz

SMA-f(50Ω)DC-13GHz1000W10W

1.6@0-4GHz

1.8@4-8GHz

2.0@8-13GHz

0.5dB0-4GHz

0.7dB@4-8GHz

1.0dB@8-13GHz

LPHF-02D22.92-f(50Ω)DC-18GHz1000W

100W@2GHz

35W@8GHz

10W@18GHz

1.35@0-8GHz

1.5@8-18GHz

0.4dB@0-8GHz

1.0dB@8-18GHz

2.92-f(50Ω)DC-18GHz1000W10W

2.0@0-4GHz

2.5@4-8GHz

3.5@8-12GHz

4.5@12-18GHz

0.5dB@0-4GHz

1.0dB@4-8GHz

2.0dB@8-12GHz

3.5dB@12-18GHz

LPHF-02F2SMA-f(50Ω)DC-18GHz1000W

100W@2GHz

35W@8GHz

10W@18GHz

1.35@0-8GHz

1.5@8-18GHz

0.5dB@0-8GHz

1.0dB@8-18GHz

SMA-f(50Ω)DC-13GHz1000W10W

1.6@0-5GHz

2.0@5-13GHz

0.6dB@0-5GHz

1.2dB@5-13GHz

LPHF-02G2
SMA-f(50Ω)DC-8GHz1000W200W@1GHz

1.2@0-4GHz

1.3@4-8GHz

0.2dB@0-4GHz

0.4dB@4-8GHz

SMA-f(50Ω)DC-8GHz1000W10W

1.8@0-4GHz

2.2@4-8GHz

0.5dB@0-4GHz

0.8dB@4-8GHz

LPHF-03A-13SMA-K(50Ω)DC-2GHz1000w    30W@1GHz
10W@1GHz
10W@1GHz		1.51.0dB50dB详情.png
LPHF-03B3
TNC(50Ω)DC-3GHz3000W30W1.70.75dB
TNC(50Ω)DC-3GHz3000W30W1.30.75dB
SMA-f(50Ω)DC-4GHz1000W10W1.51.0dB
SMA-f(50Ω)DC-4GHz1000W10W1.51.0dB
SMA-f(50Ω)DC-4GHz1000W10W1.51.0dB
IntegratedLPC-1C12021OptionalDC-3GHz1000W20W@3GHz1.6@0-3GHz

1.2dB@3GHz

（250mm/250mm）

/详情.png
LPC-1C24021OptionalDC-3GHz1000W20W@3GHz1.6@0-3GHz

1.2dB@3GHz

（250mm/250mm）

/详情.png
LPC-1C30021OptionalDC-3GHz1000W20W@3GHz1.6@0-3GHz

1.2dB@3GHz

（250mm/250mm）

/详情.png
LPC-1C36021OptionalDC-3GHz1000W20W@3GHz1.6@0-3GHz

1.2dB@3GHz

（250mm/250mm）

/详情.png



JINPAT High Frequency Rotary Joints are also called radio frequency rotary joint, radio frequency slip ring and coaxial rotary joint. This is a special branch of slip rings that transmit radio frequency signal. Radio frequency signals refer to those signals at the frequency over 300MHz. RF rotary joints enable transmission of radio frequency signals from stationary part to rotary part. RF rotary joint has the advantage of super low data distortion and excellent anti-interference performance. JINPAT radio frequency slip ring has ultra-low insertion loss and transmission fluctuation. For these advantages, JINPAT RF rotary joints are perfectly fit for those systems with harsh standards of EMI.

JINPAT High Frequency Rotary Joints transfer DC~18GHz radio frequency signals, and can be categorized into two branches. JINPAT LPCC rotary joint features single channel and super small figure. This radio frequency slip ring transmits radio signals from 0 to 3GHz with an insertion loss less than 1.6Db. Another high frequency slip ring series is coded LPHF. Slip rings of this branch consist of single channel models and multi-channel models. Single channel LPHF rotary joint support radio frequency signals up to 50GHz; two-channel slip rings up to 18GHz; three-channel models up to 3GHz.

JINPAT High Frequency Rotary Joints are frequently used in military system devices like Inertial Navigation System, radar antenna systems, satellite communication system and so on. Generally speaking, to attain a better function, the radio frequency slip ring can be integrated with electrical slip ring to allow power and other weak electrical signal transmission. Another more high-end combination is with the optical slip ring. The photoelectrical radio frequency rotary joint is a very versatile and high standard slip ring model. For more creative solutions you can consult JINPAT team.
