Capsule - VR Slip Rings
share
DetailInstallationReview(0)
LPC-0104-0402-HD01-U2 - VR equipment; Treadmills; Game seats
Features
1、Transmission of HDMI signal, USB2.0 signal, electric signal.
2、 Double slip rings integration mechanism.
Advantages
1、Integrate a variety of signals, of which HDMI signal transmission rate reaches 2K@90HZ (ultra clear video), leading domestically
2、 Independent research and development of HDMI elbow socket
| Electrical & Electronics | Mechanical | Enviromental | |||
| Number of Circuits | 2 circuits*1.5A/1 circuit*DC/ 2 circuits*4A1 circuit*HDMI/ 1 circuit*USB2.0 | Rotating Speed | 0~100 rpm | Temperature | -20℃~+60℃ |
| Current | 4A | Contact Material | Gold-to-gold | Humidity | ≤60%RH |
| Voltage | 48V | Housing Material | Engineering plastic | Protection Grade | IP40 |
Dielectric Strength | ≥200V@50Hz | Wire Type | AWG22#/AWG26# AWG28#/ AWG30#/USB2.0 /HDMI/DC | Others | |
Insulation Resistance | ≥50MΩ@200V | Life Span | / | ||
| Electrical Noise | ≤15mΩ(Signal Ring) | Wire Length | Rotor: 250±5mm Stator: 250±5mm | ||
Related Products
JINPAT's Independently Developed Production Equipment
Provide quality assurance for slip rings!
- Machining Equipment
- CNC Test Equipment
- Environmental Testing Equipment
- High-Low Temperature Test Equipment
- Machining Equipment
- Slip Ring Life Test Equipment
What is large current slip ring?
Large current slip ring is a slip rings can transmitting large power/high current from a stationary part to a rotating part, preserving and isolating the electrical connection. Moflon's high current electric slip rings are high performance, low-cost alternatives to electric slip rings. Because they can function as rotary electrical connectors when high current is required, they are especially well suited for use in heating elements.
Thanks to our unique channeled brush technology, the contact pressure between the slip ring’s brushes and rotor are greatly reduced. This, coupled with multiple brush contact points, greatly extends working life and allows these devices to be used on continuously operating machinery.
