LPFO-01D Fiber Optic Slip Ring

copy Link

Facebook

Number of Circuits 1

Lead Size Φ17/Φ26*27.5

Wavelength range 650-1650nm （ customized）

Insertion loss Single-Channel＜2dB

Insertion loss ripple Single-Channel＜0.5dB

Return Loss ＞40dB

Optional Single can be customized,housing material and driving connector are optional

Consult immediately

DetailInstallationReview(0)

LPFO optical slip rings are also known as fiber optic rotary joints, optical rotatory connector. The optical slip ring adopts optical fiber as media. It offers the best solution to transmit great capacity data and signals. The optical slip ring can be integrated with traditional electrical slip rings. The hybrid slip ring model is able to transmit power, signals and high speed data.

Specifications
Fiber types	SM or MM	Connector types	FC/SC/ST/LC(PC or APC)
Channel number	1	Estimated life cycle	＞200 million revolutions
Wavelength range	SM:1270-1650nm MM:650-1300nm	Vibration	MIL-STD-167-1A
Insertion loss	＜2dB	Mechanical shock	MIL-STD-810G
Insertion loss ripple	＜0.5dB	IP rating	IP65 or IP68
Return loss	≥40dB	Max Optical power	23dBm
Storage temperature	-55~+85℃	Maximum speed	2000rpm
Weight, approx	10g（No tail cable andconnection included）	Jacket types	0.9/2/3mm(Kevlar/PVC or Armor)
Package style	Pigtails on both ends	Working temperature	-45～+80℃
