LPFO-01B Fiber Optic Rotary Joints

Number of Circuits 1
Lead Size Φ6.8/Φ10*28
Wavelength range 650-1650nm ( customized)
Insertion loss Single-Channel<2dB
Insertion loss ripple Single-Channel<0.5dB
Return Loss >40dB
Optional Single can be customized,housing material and driving connector are optional
Consult immediately
DetailInstallationReview(0)

LPFO optical slip rings are also known as fiber optic rotary joints, optical rotatory connector. The optical slip ring adopts optical fiber as media. It offers the best solution to transmit great capacity data and signals. The optical slip ring can be integrated with traditional electrical slip rings. The hybrid slip ring model is able to transmit power, signals and high speed data.








Specifications
Fiber typesSM or MMConnector typesFC/SC/ST/LC(PC or APC)
Channel number1Estimated life cycle>200million revolutions
Wavelength range

SM:1270-1650nm

MM:650-1300nm

VibrationMIL-STD-167-1A
Insertion loss<2dBMechanical shockMIL-STD-810G
Insertion loss ripple<0.5dBIP ratingIP65 or IP68
Return loss≥40dBMax Optical power23dBm
Working temperature-45~+80℃Maximum speed2000rpm or more
Storage temperature-50~+85℃Jacket types0.9/2/3mm(Kevlar/PVC or Armor)
Weight, approx10g(No tail cable andconnection included)Package stylePigtails on both ends
