Slip Ring for Stage Rotation Equipment
Engineered for high-demand stage automation, the LPA000-04120 High Current Slip Ring features JINPAT-developed 120A carbon brushes . These brushes deliver 30% lower wear rates, ensuring uninterrupted power transfer for LED walls, motorized stage turntables, and heavy-duty lighting rigs. The ultra-compact design reduces footprint by 30% while maintaining IP66-rated environmental resilience, with customizable shapes and sealing configurations to fit concealed installations in theaters, concert arenas, and mobile exhibition systems. It embodies JINPAT’s commitment to merging cutting-edge R&D with real-world performance.
Electronic & Electric | Mechanical | |||
Circuits | Total | 4 | Working Speed | 100RPM |
Detail | 4*120A | Bore Diameter | / | |
Rating Voltage | 380V AC/DC | Contact Material | Copper Stone Ink | |
Dielectric Strength | 1000VAC@50Hz | Housing | stainless steel304 | |
Insulation Resistance | ≥500MΩ@1000VDC | Installation | Vertical Installation | |
Environment | Remarks | |||
Working Temperature | -20°C~+80°C | Application | Stage Rotation Equipment | |
IP | IP66 | Other | / | |
JINPAT Slip Rings: Engineered for Precision, Durability, and Extreme Environments.
