LPT050-Through-bore Slip Rings

share
copy Link
Facebook
Twitter
LinkedIn
Current 5A/Signal/10A/15A
Voltage 240V/DC
Consult immediately
DetailInstallationReview(0)

LPT050 Series Slip Ring with Through Bore 50mm

A slip ring can be used in any electromechanical system that requires unrestrained, continuous rotation while transferring power or data from a stationary to a rotating structure. The LPT050 uses JINPAT fiber brush technology which offers several advantages over conventional slip ring contacts including multiple points of contact per brush bundle, low contact friction per fiber and low contact wear rates. In addition,
fiber brushes do not require lubrication and produce virtually no wear debris. The LPT050 features field serviceable brush blocks.



Electronic & ElectrucMechanical
CircuitsTotal6CKTWorking Speed0~303RPM
Detail6X5AInner DiameterΦ50mm
Rating Voltage240VAC/ DCContact MaterialPrecious Metal
Dielectric Strength1000VAC@50HzHousing MaterialAluminum Alloy
Insulation Resistance≥500MΩ@500VDCLead Wire Length

Stator:300mm

Rotor:300mm

EnvironmentRemarks
Working Temperature-20°C~+60°Other/
Working Humidity≤60%RH



LPT050-0605-Outline Drawing

LPT050-0605 (2).png


LPT050-0610-Outline Drawing






LPT050-0615-Outline Drawing


LPT050-0615 (2).png


LPT050-1205-Outline Drawing





LPT050-1210-Outline Drawing


LPT050-1210 (2).png

LPT050-1215-Outline Drawing





LPT050-1805-Outline Drawing




LPT050-1810-Outline Drawing




LPT050-1815-Outline Drawing

LPT050-1815 (2).png


LPT050-2405-Outline Drawing



LPT050-2410-Outline Drawing


LPT050-2415-Outline Drawing
