LPPL06-02A-EN Standard Pneumatic air rotary union
share
DetailInstallationReview(0)
air rotary union Description:
A hydraulic rotary joint is a mechanism used to transfer fluid (under pressure or vacuum) from a stationary inlet to a rotating outlet, preserving and isolating the fluid connection.
Pneumatic rotary joint are engineered to endure a wide range of temperatures and pressures for a variety of conditions and environments. In addition, rotary unions may integrate multiple passages and handle different types of fluid simultaneously.
| Rotary Unions & Joints Spec | Mechanical Data | ||
| Max.Operating Pressure | Positive Pressure 1Mpa,Vacuum -1.5kpa | Working Speed | 0~100RPM |
| Medium Type | Air | Working Temp | -20°C~+60°C |
| Passages(Gas/Flow) | 2in 2out | Work Humidity | ≤60%RH |
| Pipe Size | φ4mm pipe,M5 port | Housing Material | Aluminum Alloy |
| Torque | ≤1.0 N.m | IP Grade | IP51 |
Havn't found standard size of large current slip rings to fit my application?
1) View "Customized Solutions", you can find more large current slip rings solutions.
2) Customize your dimension for large current slip rings and Contact us : sales@electricslipring.com
