LPT000-0810-0405-2E2

copy Link

Facebook

Number of Circuits 8*10A+4*5A+2*E2

Current 10A/5A

Voltage 24/38V

IP IP51

Consult immediately

DetailInstallationReview(0)

LPT000-0810-0405-2E2 Through Bore Slip Ring(with 100Mbps Ethernet channel)

The LPT000-0810-0405-2E2 Through Bore Slip Ring offers current and multi-signal channels, including 100Mbps Ethernet signal transmission capability. Equipped with precious metal contacts and an IP51 rating, it ensures stable operation in demanding environments. Designed for automation, robotic arms, and smart manufacturing, this slip ring delivers reliable performance and extended lifespan.

Electronic & Electric			Mechanical
Circuits	Total	14	Working Speed	0~20rpm
	Detail	2×10A+4×5A+2×100Mbps Ethernet	Inner Diameter	/
Rating Voltage		24/380V	Contact Material	Precious Metal
Dielectric Strength		Power≥1000V@50Hz Signal≥100V@50Hz	Housing Material	Aluminum Alloy
Insulation Resistance		Power≥1000MΩ@1000VDC Signal≥ 100MΩ@100VDC	Lead Wire Length	Stator:3000mm Rotor:1500mm
Environment			Remarks
Working Temperature		-20°C~+80°C	Application	Robot arms/automation equipment/intelligent manufacturing equipment
Working Humidity		≤60%RH
IP		IP51
